Chapter 6

Operating Modes

A CueCore2 can operate in three modes, each mode resulting in a different
behaviour of the device.
Stand-alone
Slave
CueluxPro
By default the CueCore2 operates in the Stand-alone mode.
The status bar at the bottom of the web-interface (figure 6.1) indicates the
current operating mode. When mastered by CueluxPro the home page of the
web-interface show the IP address of the CueluxPro system (figure 6.2).
6.1 Stand-alone mode
In this mode the CueCore2 is an autonomous device for controlling lighting.
Typically it is loaded with lighting content and programmed to respond to
external triggers and/or internal scheduling. This is the default behaviour of a
CueCore2; the stand-alone mode is active whenever the CueCore2 is not in the
slave or CueluxPro mode.
Figure 6.1: Status bar
Figure 6.2: Master IP
