3 - Preventive Maintenance Procedure
3.3

Clean All Transport Rollers

Follow these steps to clean the rollers on the hopper transport, XY transport, and exit transport. Use the
white cleaning cards:
1) Remove hoppers 1 and 2.
2) Remove the tipper foil cartridge and set it aside in a secure location, or offer it to the customer for
temporary storage or secure disposal.
3) On the touchscreen, navigate to
Controller Commands
4) Use the white cleaning card and do not let the rollers take it out of your hand as you clean each set
of rollers as follows:
a) Feed the card partly into the hopper transport and press the
there until the rollers stop moving.
Figure 3-1 - Cleaning the Hopper Transport Rollers (TOP VIEW FROM FRONT)
b) Feed the card partly into the left side of the exit transport and press the
the card there until the rollers stop moving.
Figure 3-2 - Cleaning the Left Side of the Exit Transport (TOP VIEW FROM FRONT)
c) Feed the card partly into the right side of the exit transport and press the
Push inward to keep the card from being pushed out until the rollers stop moving.
ExpressCard 2000| Instant Issuance Card Personalization System | Preventive Maintenance Procedure
>
Menu Settings
page.
Page 8 of 25 (D99875651-25)
> >
Service MCP Cmds
Roll to Printer
to open the
button. Hold the card
button. Hold
Exit Eject
button.
Exit Reject
