1 - Required Tools, Materials, and Documents

1 Required Tools, Materials, and Documents
1.1

Required Tools

Part Number
33011008
67800019 or equiv.
N/A
N/A
1.2

Suggested Tools

Part Number
N/A
22350302 or equiv.
N/A
1.3

Required Materials

Part Number
97200153
1.4

Suggested Materials

Part Number
33011009
93400047
33070896
33070621
1.5

Required Software and Documents

MagTek recommends loading the following required software and documents on the USB thumb drive or
service laptop before visiting the customer site.
Part Number
99875600
99875607
99875651
99875646
N/A
VARIOUS
ExpressCard 2000| Instant Issuance Card Personalization System | Preventive Maintenance Procedure
Quantity
1 ea. ASM TOOL KIT,FIELD SERVICE,EC2000
1 ea. Small USB keyboard with touchpad mouse
1 ea. Small diagonal side cutters
1 ea. USB thumb drive with required software and documentation
Quantity
1 ea. Laptop with available Ethernet port
1 ea. 10 ft. Ethernet cable (COM ETHERNET CAT5E BLK 10')
1 ea. Flashlight
Quantity
1 ea. ASM KIT,PREVENTIVE MAINTENANCE,EC2000
Quantity
1 ea. ASM KIT,STARTER,SPARE,FIELD SERVICE,EC2000
1 ea. PRI RIBBON, COLOR YMCKOK EV (R3314)
1 ea. ASM RIBBON ASSY,TIP FOIL,SILVER
1 ea. AAY ASSY,INDENT CARTRIDGE
Quantity
1 ea. MNL USER INSTALL & OPERATION MANUAL,EC2000
1 ea. MNL HARDWARE SERVICE MANUAL,EC2000
1 ea. REF PROCEDURE,PREVENTIVE MAINTENANCE,EC2000
1 ea. REF CHECKLIST,PREVENTIVE MAINTENANCE,EC2000
1 ea. Passwords and factory defaults for the device being serviced
EC2000 software patch .CAB files provided by MagTek Support
0 or more
Services, loaded onto USB thumb drive or service laptop
