Step 7
INSTALLING THE DOORS SENSOR
Make sure you have prepared the door sensors for installation, see step 4
LOCK SENSOR (P)
Install on the interior side only. If necessary, trim tab from sensor (P) for doors with 2-3/8"
(60mm) backset. Clean surface of door and doorframe, remove film from adhesive,
attach and secure close to door edge as shown.
(P)
2-3/4"
(70mm)
2-3/8"
(60mm)
15
