- Page 1 Korenix JetPort Serial Device Server User’s Manual Oct. 2008 (V1.1) www.korenix.com...
- Page 2 Korenix JetPort Serial Device Server User’s Manual Copyright Notice Copyright © 2006 Korenix Technology Co., Ltd. All rights reserved. Reproduction in any form or by any means without permission is prohibited.
-
Page 3: Table Of Contents
Contents Chapter 1 Introduction of JetPort................1-1 Serial to Ethernet Technology Overview ............1-2 Product Features ....................1-2 Product Specification..................1-2 Package Checklist .................... 1-4 Chapter 2 Quick Start ....................2-1 Hardware Installation..................2-2 Panel and Interfaces..................2-2 Reset Button....................2-2 LED Indicators ....................2-2 Connecting the Power ..................2-3 Connecting to the Network ................2-3 Connecting to the Serial Device ..............2-3... - Page 4 Service Mode- UDP..................4-6 Access IP Table ....................4-6 Event Notification..................4-7 Email and SNMP Trap Notification ...............4-8 Save / Restart....................4-8 Telnet Console ....................4-8 Configuration ....................4-9 Appendix A SNMP MIB II and RS232 Like Support ..........A-1 Appendix B RS232 Pin Assignment ................B-1...
-
Page 7: Introduction Of Jetport
Introduction of JetPort Chapter 1 Jetport 5201 is a smart one RS-232 to Ethernet serial device server. It connects the serial port of devices such as card readers, measurement devices, or data acquisition terminals, over Ethernet just like locally attached. JetPort serial device server eliminates the limitation of single host and transmission distance of traditional serial communications by creating access for multiple hosts in Ethernet. -
Page 8: Serial To Ethernet Technology Overview
Serial to Ethernet Technology Overview Korenix JetPort serial device servers provide perfect solution to manage serial devices via Ethernet in flexible ways, such as TCP server, TCP client, UDP, or Windows virtual COM. JetPort creates a transparent gateway for the serial communication to Ethernet. If the control program uses network standard API, you can choose TCP or UDP as the communication protocol. - Page 9 Introduction Serial Line 15KV ESD Protection Software Utility JetPort Commander for Windows NT/2000/XP Utility Device discovery Auto IP report Device setting (run-time change, no rebooting) Access control list Group setting Device monitoring Serial port monitoring Log info Group Firmware update batch Serial mode Virtual Com / TCP Server / TCP Client / UDP / Serial Tunnel TCP Alive Check Timeout...
-
Page 10: Package Checklist
Package Checklist JetPort is shipped with the following items: Korenix JetPort Serial Device Server 100-240V Power adapter Mounting kit and 4 screws 4 Foot pads Documentation and Software CD Quick Installation Guide If any of the above items is missing or damaged, please contact your local sales representative. -
Page 11: Chapter 2 Quick Start
Quick Start Chapter 2 JetPort serial device server can be configured by Windows utility, web browser, or Telnet console. Advanced management features include SNMP support and Email alert. JetPort Commander is a powerful Windows utility that supports device discovery, group setup, group firmware update, and monitoring functions. -
Page 12: Hardware Installation
Hardware Installation Panel and Interfaces 12VDC (9~30 VDC) Auto MDI/MDIX 1 KV Burst (EFT), EN61000-4-4 10/100M Ethernet 0.5 KV Surge, EN61000-4-5 Built-in 1.5 KV magnetic Reset Button Reset IP address and configuration to default Power/Ready LED Ethernet Link/Act LED Serial TX/RX LED Mounting kit 1 RS-232 port, DB9 15 KV ESD for all signals... -
Page 13: Connecting The Power
5201”, and “Operation System”, run JetPort Setup.exe to install Windows utility, JetPort Commander. When the installation is finished, there are three options: Launch JetPort Commander Now: Start configurations. Visit Korenix registration page: Register products to Korenix. Launch JetPort later: Start configurations later. JetPort Serial Device Server User’s Manual... - Page 14 Broadcast the JetPort unit: JetPort Commander will broadcast the network and search all available JetPort units in the network. The default IP address of JetPort is “192.168.10.2”. Product Tip: If you have multiple Network Adapters (i.e. wireless and wired), please activate ONLY ONE Network Adapter that can locate the JetPort devices, and CLOSE the rest Network Adapters.
- Page 15 Quick Start Configuring the serial port as COM port: Go to “Configuration”, and choose the “device” and the “port”. Select “Serial Settings” to configure the serial parameters Select “Service mode” , “Virtual COM Mode” and press “Map Virtual COM” to map the port to the COM port.
-
Page 17: Windows Management Tool
Windows Management Tool Chapter 3 JetPort serial device server provides powerful Windows management tool for multiple device management. This chapter introduces major functions in JetPort Windows Commander Server Configuration Broadcast Configuration General Locate Security Networking Notification Management Firmware Update Save / Reload Port Configuration Port Serial Settings Port Service Mode... -
Page 18: Server Configuration
Server Configuration Server configuration covers all settings for the device. Before you start, you need to add the devices first in the configuration list. Broadcast After installing JetPort Commander, you can broadcast for all available devices on the network. Choose “Broadcast” button in the quick bar, and start to search. Select the device you wish to add and click “Add”. -
Page 19: Locate The Device
Windows Management Tool The General section lists information of “Model”, “Firmware Version”, “IP Address”, and “MAC Address”. You can modify Device Name and remark Location information. Using SNTP Time Server: Enable Time Server by specifying SNTP server IP and Port. Auto IP Report: If this device uses DHCP or BootP IP, enable Auto IP Report will report its dynamic IP address to the specified host regularly. -
Page 20: Networking
You can assign password to protect others from changing the configurations on the device. If you assign password, you will need to give password every time when you access Windows, Web, or Telnet consoles. The password will also validate on Setup Wizard configuration. You can input max. - Page 21 Windows Management Tool The length of community is from 1 to 31, which cannot be left blank and do NOT include “;” mark. The length of Location and Contact information is from 0 to 255, which is optional. The Trap Server supports domain name format, and requires at least one Trap Server information to activate the setting.
- Page 22 Email Notification Enabling Email notification will open a windows for SMTP settings. Assign SMTP server, and if Authentication is required for the SMTP server, check the authentication box and specify the users name and password. JetPort supports sending notification to max. 4 email addresses. System Log Server Notification Enabling Syslog Notification will open Syslog Settings window.
-
Page 23: Management
Choose “Apply Only” or “Apply and Save” to validate the changes. Update Firmware You can find up-to-date firmware of JetPort in Korenix website download section. http://www.korenix.com/support_downloads.htm To update Firmware of the device, save the firmware file in your host PC. Go to “Configuration”, and “Update Firmware”. -
Page 24: Port Configuration
Port Configuration Serial Port Configurations include configuration for the serial parameters, serial communication modes, data packing options, and event notifications. Go to the port of the device in Configuration tree. Choose “Apply Only” or “Apply and Save” to validate the changes. Serial Settings The available serial settings for JetPort is as follows: Port Alias: Remark the port to hint the connected device. -
Page 25: Service Mode- Virtual Com
Windows Management Tool Choose “Apply Only” or “Apply and Save” to validate the changes. Service Mode- Virtual COM Virtual COM service mode enables the serial port in JetPort as PC’s locally-attached COM port for Windows or tty port for Linux. One PC can have as many as COM ports on the network without the limitation of PC’s physical slots. - Page 26 Select the available port number to map to. When the configuration is finished and saved, the COM port number will be shown after port, and you can monitor the port in Monitor menu. Multiple Virtual COM Connections Max. one connection is default. To create multiple Virtual COM connection, select max. connection number that the JetPort device is allowed.
-
Page 27: Service Mode- Tcp Server
Windows Management Tool Miscellaneous Settings: Idle Timeout: When serial port stops data transmission for a defined period of time (Idle Timeout), the connection will be closed and the port will be freed and re-try for connection with other hosts. Zero is disable this setting (default). If Multilink is configured, only the first host connection is effective for this setting. - Page 28 TCP Server proceeds as follows: 1. Network host requests a TCP connection with JetPort in TCP Server Mode by IP address and port number. 2. Once the connection is established, data can be transmitted in both directions from the host to the JetPort device, and vice versa.
-
Page 29: Service Mode- Tcp Client
Windows Management Tool Idle Timeout: When serial port stops data transmission for a defined period of time (Idle Timeout), the connection will be closed and the port will be freed for other hosts. Zero is disable this setting (default). If Multilink is configured, only the first host connection is effective for this setting. -
Page 30: Service Mode- Udp
Miscellaneous Settings: Idle Timeout: When serial port stops data transmission for a defined period of time (Idle Timeout), the connection will be closed and the port will be freed and re-try for connection with other hosts. Zero is disable this setting (default). If Multilink is configured, only the first host connection is effective for this setting. - Page 31 Windows Management Tool To configure UDP, select UDP Mode in Service Mode of Port Configuration. “Auto Scan” the Listening port number of JetPort. If there are more than one destination hosts, specify the IP address range by Destination Host IP Begin and End.
-
Page 32: Notification
Notification Port status can be notified to administrator by means of Email, SNMP trap, or System Log. The events for notification include: DCD changed: When DCD (Data Carrier Detect) signal changes, indicating the modem connection status has changed, the event will be triggered. RI changed: When RI (Ring Indicator) signal changes, indicating the incoming of a call, the event will be triggered. -
Page 33: Setup Wizard
Windows Management Tool After modifying configuration, be sure to validate the changes by using “Apply Only” or “Apply and Save”. Setup Wizard JetPort Commander offers 5 Setup Wizards to help you manage JetPort devices as a group and streamline the management tasks. 3-17 JetPort Serial Device Server User’s Manual... -
Page 34: Virtual Com Wizard
Virtual COM Wizard JetPort Commander offers one of the easiest way to add serial COM ports over the network by the Virtual COM Wizard. JetPort COM port driver is installed when you install JetPort Commander. Select the Virtual COM Wizard from Setup Wizard. There are only 3 steps to follow up. Select the available ports of JetPort devices on the network. -
Page 35: Serial Tunnel Wizard
Windows Management Tool Specify the Virtual COM port range and continue the operation by checking the COM port table. Serial Tunnel Wizard The Serial Tunnel Wizard gives you the option to transparently pair two devices over the network. Select the devices that should be paired and move the devices into IP1 and IP2. After configuring the serial setting of the ports, the serial tunnel will be built by assigning one port as the TCP Server mode and the other as the TCP Client mode. -
Page 36: Group Setup Wizard
Search the devices in local network (i.e. same subnet), or search by an IP range. Select the devices. Select the devices for group IP configuration and define the IP addresses range or by DHCP. Click next to confirm the setup and the IP configuration is finished, you will see the IP addresses for the devices. - Page 37 Windows Management Tool Select device model as “JetPort 5201”. Select the source device for the configuration and destination devices. Specify the configuration items from the source device to the destination devices. Click next to confirm and finish the wizard. 3-21...
-
Page 38: Group Firmware Wizard
Group Firmware Wizard To update firmware for a group of devices can be as easy as 4 steps of Group Firmware Wizard. Select the device model as JetPort 5201, and select available devices on the network for the upgrade. Specify the firmware image and select next. Confirm the firmware upgrade and continue operation. -
Page 39: Ip Collection
Windows Management Tool IP Collection For the dynamic DHCP IP settings, it is often a task to find the changing IP addresses. JetPort Commander supports auto IP report function to report the current IP address of the JetPort units to administrator. To enable the function, check “Auto IP Report” in “Configuration”, “General”. -
Page 40: Monitor
Monitor You can monitor the COM port status from the Monitor function. The monitored items can also be defined by the “Select Monitor Items”. You must configure the COM ports first before monitoring the status. 3-24 JetPort Serial Device Server User’s Manual... -
Page 41: Web And Telnet Console
Web and Telnet Console Chapter 4 In addition to Windows utility, JetPort can also be managed by Web and Telnet Console. This chapter describes: Web Console Server Configuration Port Configuration Management Save / Restart Telnet Console Overview Configuration... -
Page 42: Web Console
Web Console When the JetPort has been configured with proper IP address and the web management is enabled, you can use web browser to make further configurations. Type JetPort’s IP address in the Address input box, for example 192.168.10.5. If the JetPort is password protected, use the pre-assigned password to login first. The overview page lists the basic information of this JetPort device. -
Page 43: Port Configuration- Serial Parameter
Web and Telnet Console Network Setting configures the IP address, netmask, gateway, and DNS server for the JetPort. Auto IP report is for dynamic IP address reporting in defined intervals. You can also define Administration password to protect the JetPort from unauthorized modification. -
Page 44: Service Mode- Virtual Com
Throughput mode guarantees highest transmission speed Latency mode guarantees shortest response time For advanced data packing options, you can specify delimiters for Serial to Ethernet and / or Ethernet to Serial communications. You can define max. 4 delimiters (00~FF, HEX) for each way. The data will be hold until the delimiters are received or the optional “Flush Ethernet to Serial data buffer”... -
Page 45: Service Mode- Tcp Server
Web and Telnet Console Idle Timeout: When serial port stops data transmission for a defined period of time (Idle Timeout), the connection will be closed and the port will be freed and re-try for connection with other hosts. Zero is disable this setting (default). If Multilink is configured, only the first host connection is effective for this setting. -
Page 46: Service Mode- Udp
Idle Timeout: When serial port stops data transmission for a defined period of time (Idle Timeout), the connection will be closed and the port will be freed and re-try for connection with other hosts. Zero is disable this setting (default). If Multilink is configured, only the first host connection is effective for this setting. -
Page 47: Event Notification
Web and Telnet Console The Access IP Table specifies the IP address and subnet that can access to the device. The access is based on IP and netmask combination. If the access is open to all hosts, do NOT enable this function. Event Notification Specify the events that should be notified to the administrator. -
Page 48: Email And Snmp Trap Notification
Email and SNMP Trap Notification Email Server configuration includes the mail server’s IP address or domain. If the authentication is required, specify the username and password. There are 4 email addresses you can specify to receive the notification. SNMP Trap configuration includes up to 4 Trap Servers. You need to at least fill in one Trap Server’s IP or domain. -
Page 49: Configuration
Web and Telnet Console Configuration Configure the device and port by pressing function number or the hinted initial. Press “q” to exit the function. Always press “a” to apply and save change after making a configuration. JetPort Serial Device Server User’s Manual... - Page 51 SNMP MIB II and RS232 Like Support Appendix A Jetport 5201 has build-in SNMP agent that supports SNMP trap, RFC 1317 RS232 MIB and RFC1213 MIB-II. The following tables list SNMP variables implemented in Jetport 5201. RFC1213 MIB-II supported SNMP variables...
- Page 52 ipRouteMetric1 ipRouteNextHop ipRouteType ipRouteProto ipRouteMask ipRouteInfo ipNetToMediaIfIndex ipNetToMediaPhysAddress ipNetToMediaNetAddress ipNetToMediaType ipRoutingDiscards ICMP MIB icmpInMsgs icmpInErrors icmpInDestUnreachs icmpInTimeExcds icmpInParmProbs icmpInSrcQuenchs icmpInRedirects icmpInEchos icmpInEchoReps icmpInTimestamps icmpInTimestampReps icmpInAddrMasks icmpInAddrMaskReps icmpOutMsgs icmpOutErrors icmpOutDestUnreachs icmpOutTimeExcds icmpOutParmProbs icmpOutSrcQuenchs icmpOutRedirects icmpOutEchos icmpOutEchoReps icmpOutTimestamps icmpOutTimestampReps icmpOutAddrMasks icmpOutAddrMaskReps TCP MIB tcpRtoAlgorithm tcpRtoMin tcpRtoMax...
- Page 53 FAQs rs232PortInSpeed rs232PortOutSpeed rs232PortInFlowType rs232PortOutFlowType rs232AsyncPortIndex rs232AsyncPortBits rs232AsyncPortStopBits rs232AsyncPortParity rs232AsyncPortAutobaud rs232AsyncPortParityErrs rs232AsyncPortFramingErrs rs232AsyncPortOverrunErrs rs232InSigPortIndex rs232InSigName rs232InSigState rs232InSigChanges rs232OutSigPortIndex rs232OutSigName rs232OutSigState rs232OutSigChanges JetPort Serial Device Server User’s Manual...
- Page 55 RS232 Pin Assignment Appendix B Pin No. Name Notes/Description Data Carrier Detect Receive Data (RxD, Rx) Transmit Data (TxD, Tx) Data Terminal Ready SGND Ground Data Set Ready Request To Send Clear To Send Ring Indicator...
- Page 56 Revision History Appendix C Version Description Date V1.0 The first version. Mar. 2006 V1.1 Correct Serial Port LED color Oct. 2008 JetPort Serial Device Server User’s Manual...
