Step 3
1. Install one side of the Cable (75) on the Bearing (57) tightly.
2. Install the other side of the Cable (75) according to the arrows in the picture shown.
Note: The Cable (75) have to pass through the hole in the lower right corner of the Front
plastic shroud (59).
3. Lock the Pulley fixed combination (8) on the Handlebar frame (4) with Hex socket head cap
bolt (22), Flat washer (38) and Nylon nut (33).
4. Pre-lock the Pulley cover (26), Alloy bush (50), Pulley (74) on the Seat frame (1) with Hex
socket head cap bolt (18), Flat washer (37) and Cap nut (35).
5. Pre-lock the Pulley (74) and Alloy bush (50) on the Weight frame (2) with Hex socket head
cap bolt (18), Flat washer (37) and Nylon nut (32).
6. Lock all the pre-locked bolts tightly now.
