6 0-250
251-255
7 0-7
8-87
88-167
168-255
8 0-7
8-36
37-66
67-96
97-126
127-156
157-186
187-216
217-246
246-255
9 0-255
10 0-7
8-240
241-255
11 0-9
10-255

Technical Specifications

•
Power supply: 100-240V AC, 50/60Hz
•
Power consumption: 45W
•
Light Source:
o
Derby: 2pcs 12W RGBW LEDs
o
Strobe: 24pcs 0.2w SMD White LEDs
o
Laser: 532nm/30mW (Green) laser diode, 650nm/100mW (red) laser diode
•
Lifetime: 50,000 hours
•
Control Panel: 4 digital LED display figures
•
Control Mode: Sound activated, Auto, Master/Slave, DMX512, IR Remote
•
DMX Channels: 2 / 11
•
Dimensions: 320x320x320 (package)
•
Weight: 3.35kg

Warranty

Please refer to your local dealer or contact Event Lighting Pty Ltd.
Laser Strobe effect
Laser rotation
Strobe mode
(centre, can add
effects on top)
Strobe effect speed
Strobe effect
Derby Rotation
www.event-lighting.com.au
9
Speed from slow to fast
Sound activated
No rotation
Backwards rotation, slow to fast
Forwards rotation, fast to slow
Random rotation
No function
No Strobe
Strobe effect 1
Strobe effect 2
Strobe effect 3
Strobe effect 4
Strobe effect 5
Strobe effect 6
Strobe effect 7
Strobe effect 8
Ch. 8 effect speed, slow to fast
No Strobe
Strobe speed, slow to fast
Sound activated
None
Motor rotation, slow to fast
