Removing the Top

1.
Remove both outer sides by
performing steps 1 and 2 on page 2.
2.
Remove two (2) #8-18 x 3/8"
screws from each side of the
underside of the top.
3.
Top slides off from side-to-side.
NOTE: Top will only slide one
direction, either left to right or right to
left. Try one, if that doesn't work,
slide it the other direction. Note
which way you slid it off.
4.
Re-install the top by reversing
steps 1 thru 3. Make sure you slide
the top on the opposite direction
(reverse) of how it slid off and that all
top clips are properly engaged. (You
can check this by pulling up gently
along the length of the top - both front
and back. The top should not lift off).
#8-18 X 3/8" SCREW
2
TOP
3
OR
939500421 Rev A
Page 3 of 5
