Removing Outer Side
1.
Remove three (3) #8-18 x 3/8"
screws.
2.
Gently pull the bottom flange of
the outer sides out past the inner
side flange (Fig.1) and then pull
toward the bottom of the unit to
disengage the inner side hooks
(Fig. 2). Remove sides.
3.
Re-install the side by reversing
steps 1 and 2.
OUTER SIDE
2
#8-18 X 3/8" SCREW
1
Fig. 1
FLANGE OF
OUTER SIDE
Side View
Fig. 2
BOTTOM
INNER SIDE
FLANGE
Page 2 of 5
939500421 Rev A
