Projector exterior view

1
2
3
4
5
19
3
19
3
1. Focus ring
2. Vent (air exhaust)
3. Adjuster feet
4. Projection lens
5. IR remote sensor
6. External control panel
(See Controls and functions on page
7. Lamp cover
8. Vent (air inlet)
9. Audio input jacks
Audio output jack
10. RGB (PC) signal output jack
6
7
8
3
19
20
11. RS-232 control port
12. RGB (PC) signal input jacks
13. HDMI input port
14. RJ-45 LAN input jack
15. USB Mini-B port
16. USB Type A port
10.)
17. USB Type A port
18. AC power jack
19. Wall mount holes
20. Security bar
21. USB Type A port (for wireless dongle)
22. Wireless dongle cover
10 12
9 11
22
18
14 16
13 15 17
21
