Digital Projector
User Manual
Portable Entertainment Series | GV1
V 1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Portable Entertainment Series and is the answer not in the manual?

Questions and answers

Related Manuals for BenQ Portable Entertainment Series

Summary of Contents for BenQ Portable Entertainment Series

  • Page 1 Digital Projector User Manual Portable Entertainment Series | GV1 V 1.00...

  • Page 2: Copyright And Disclaimer

    BenQ warrants this product against any defects in material and workmanship, under normal usage and storage. Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ’s only obligation and your exclusive remedy shall be replacement of any defective parts (labor included).

  • Page 3: Statement Regarding Hyperlinks And Third-Party Websites

    Any third party content or service preinstalled in this product is provided "as is". BenQ does not, by expression or by implication, make any warrant to the content or to the services provided by third parties. BenQ does not warrant or guarantee that the content or services provided by third parties are accurate, effective, most up-to-date, legal, or complete.

  • Page 4: Table Of Contents

    Table of contents Copyright and disclaimer ...................................2 Copyright ........................................... 2 Disclaimer ..........................................2 Warranty............................................ 2 Statement regarding hyperlinks and third-party websites ..........................3 Package contents .......................................11 Standard accessories ......................................11 Introduction ........................................14 Projector features ........................................14 Projector exterior view ...................................... 16 Front and left side view ............................................
  • Page 5 Correcting keystone ...............................................39 BenQ Launcher ..................................... 40 The BenQ Launcher home page........................................40 Navigating the BenQ Launcher home page....................................41 Using the BenQ Launcher Settings Menus ....................................42 Inputting text ................................................42 Connections ....................................... 44 Wireless Connections ......................................46 Connecting the projector to a Wi-Fi network....................................46 iOS Mobile Projection ............................................48...
  • Page 6 Wi-Fi Hotspot ........................................55 Wired Connections.......................................59 Connecting a USB-C™ device with DisplayPort..................................... 59 Connecting a USB-C™ device without DisplayPort ..................................62 Connecting a USB-C™ flash drive ........................................63 Media Player ................................................64 Bluetooth Connections ......................................73 Pairing/Connecting to a Bluetooth speaker or headphones ................................. 73 Using the Projector as a Bluetooth speaker.....................................
  • Page 7 Specifications ......................................94 Projector specifications ............................................94 Dimensions................................................97 Timing chart ................................................98 10/25/2018...
  • Page 8 Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. 1.
  • Page 9 If the projector does become wet, disconnect it from the power point and call BenQ to have the projector repaired. 5. Do not block the vents holes while the projector is on (even in standby mode).
  • Page 10 Moisture condensation 12. This projector is capable of displaying inverted images for ceiling installation. Never operate the projector immediately after moving it from a cold location to a hot location. When the projector is exposed to such a change in temperature, moisture may condense on the crucial internal parts.

  • Page 11: Package Contents

    Package contents Carefully unpack and verify that you have the items below. Some of the items may not be available depending on your region of purchase. Please check with your place of purchase. Standard accessories GV1 Projector USB-C™ Cable Remote Control Adapter Adapter Plug Head (US) Adapter Plug Head (EU)
  • Page 12 Adapter Plug Head (UK) Adapter Plug Head (CHINA) Adapter Plug Head (AUS) Digital Projector Quick Start Guide Portable Entertainment Series | GV1 V1.00 Carry Bag Regulatory Statement Quick Start Guide Warranty Card...
  • Page 13 • Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specifications are subject to change without notice. • Some of the accessories may vary from region to region. • The warranty card is only supplied in some specific regions. Please consult your dealer for detailed information. •...

  • Page 14: Introduction

    Convenient Android-based BenQ Launcher The projector operates through the Android-based BenQ Launcher which is complemented by a WLAN connection that allows you to project/broadcast media via embedded or downloaded streaming apps. (The app market will be introduced by OTA update in late 2018) •...
  • Page 15 The projector features a long lasting LED lightbulb that provides a longer lifespan than traditional bulbs. • Low Heat Unlike other projectors, GV1 emits lower temperature, making it safe enough for inquisitive children to touch without hurting their hands.

  • Page 16: Projector Exterior View

    Projector exterior view Front and left side view 1. Control panel (See Control panel on page 18 for details.) 2. Projection lens 3. Front IR sensor 4. Focus ring...

  • Page 17: Rear And Right Side View

    Rear and right side view Connections on page 44 for connection details. 5. Speaker grill Inside the speaker grill is the rear speaker. 6. USB-C™ port Used to connect devices with DisplayPort functionality to project video from the device or flash drives to project/broadcast media stored on the card. 7.

  • Page 18: Controls And Functions

    Controls and functions Control panel Switch mode key/LED indicator • Toggles the Bluetooth speaker on and off. • Acts as an LED indicator for Bluetooth and errors. See LED Indicators on page for more details. Volume down key Decreases the projector volumes. Power key/LED indicator •...

  • Page 19: Led Indicators

    LED Indicators The power and switch mode keys feature LEDs that help indicate the status and possible operating errors for the projector, refer to the table below for definitions of various LED behaviors. Power Key Switch Mode Key Scenario Status LED Behavior Schema LED Behavior...
  • Page 20 Power Key Switch Mode Key Scenario Status LED Behavior Schema LED Behavior Schema LED error Yellow - solid Red - flashing Fan error Red - solid Red - flashing Optical engine temperature Error* Red - solid error Battery temperature error Red - flashing Driver board error Red - flashing...

  • Page 21: Remote Control

    Settings Launches the BenQ Launcher settings menu. HOME Press this key to enter the BenQ Launcher home menu This key is only active when the projector is under BenQ Launcher mode. Volume Down Decreases the projector volume. 6. OK Used to confirm the selection on the BenQ Launcher menu.

  • Page 22: Activating The Remote Control Battery

    Activating the remote control battery Before you can begin to use the remote control, you must first remove the clear plastic battery sticker between the battery and the contact on the remote control. 1. Use a flat-tipped instrument to rotate the battery cover counter-clockwise to the unlocked position. 2.

  • Page 23: Replacing The Remote Control Battery

    Replacing the remote control battery 1. Use a flat-tipped instrument to rotate the battery cover counter-clockwise to the unlocked position. 2. Remove the battery cover from the remote control. 3. Carefully dislodge the used battery from underneath the retention coil and slide it out from the remote control. 4.

  • Page 24: Remote Control Effective Range

    Remote control effective range The projector’s IR remote control sensor is located at the front of the projector with a range of 8 metres (~26 feet) at an angle of 30-degrees (left and right) and 20-degrees (up and down). The remote control can be used either by pointing it at the front of the projector or by reflecting the IR signal off of a wall.

  • Page 25: Installation

    Installation Choosing a location Before choosing an installation location for your projector, take the following factors into consideration: • Size and position of your screen • Electrical outlet location • Location and distance between the projector and the rest of your equipment •...
  • Page 26 3. Rear: Select this location with the projector placed near the floor behind the screen. Turn on the projector and select the following settings: Settings > Installation > Projector Installation > Rear A special rear projection screen is required. 4. Rear Ceiling: Select this location with the projector elevated from the ceiling behind the screen.

  • Page 27: Obtaining A Preferred Projected Image Size

    Obtaining a preferred projected image size The projected image size is determined by the distance from the projector lens to the screen, and the video format. The data in the table below is based on a normal projection method and not the result of adjusting the projection angle (1-15 degrees). Projection dimensions Use the illustration and tables below to help you determine the projection distance.
  • Page 28 Screen size Projector distance (mm) Diagonal H (mm) W (mm) Average Inch 1524 1329 1727 1651 1439 1871 1778 1550 2015 1905 1661 2159 2032 1771 2303 2159 1882 1058 2447 2286 1993 1120 2591 2413 2104 1182 2735 2540 2214 1245 2879...

  • Page 29: Operations

    Operations Attaching the plug head 1. Place the plug head onto the adapter. 2. Rotate the plug head clockwise until it clicks into place. Removing the plug head 1. Press the button next to the plug head on the adapter. 2.

  • Page 30: Charging The Battery

    Charging the battery 1. Charge the projector’s battery by leaving the supplied power adapter connected to the projector and a power outlet. 2. The power LED indicator will illuminate according to its charge status, for a full charge wait until the indicator lights up solid green (see Indicators on page 19 for more information on LED behavior).
