Specifications

Product
LCD Display
Display Type
Resolution Max.
Brightness
Color
Pixel Pitch
Viewing Angle
Contrast
Backlight Lifetime
Touchscreen type
Light Transmission
Controller
CPU
Memory
Storage
Network (LAN)
I/O Ports
Expansion
Speaker
OS Support
Power Supply
Power Consumption
Operating Temperature
Storage Temperature
Relative Humidity
Shock
Vibration
Safety and EMC
Dimensions
Weight
2 PPC-3151W/3211W Startup Manual
PPC-3151W-P75A
15.6"
15.6" TFT LCD (LED backlight)
1920 x 1080
450 cd/m
2
16.2M
0.17925 X 0.17925 mm
85 (Left), 85 (Right),
85 (Up), 85 (Down)
800
50, 000 hours
Multi-touch projected capacitive
88 % ± 2 %
USB interface
Intel® Core™ i5-7300U dual core (default); i7-7600U/i3-7100U(optional)
1 x SODIMM, DDR4 1866/2133, max. 16 GB (1.2V)
1 x 2.5" SATA bay;
1 x M.2 bay (size: 22 x 42 mm, socket
2 B key, for storage only)
2 x 10/100/1000 Mbps Ethernet (Intel® I211-AT; Intel® I219LM)
2 x RS-232, 1 x RS-422/485 with 1K VDC isolation
Either 2 x RS-232 or 1 x RS-232 + 1 x GPIO(TTL, 8 pin programmable) on right
side (optional module)
4 x USB 3.0,
1 x Line-out, 1 x Mic-in
1 x DB15 VGA (1920 x 1200)
1 x DisplayPort (1.2) (3840 x 2160)
1 x TPM 2.0 (optional)
1 x Mini PCIe
1 x PCIex4 (Default); 1 x PCI (in the accessory box)
2 x 1W
Microsoft® Windows 10 (64 bit); Linux
9 - 32 Vdc
65W
0 ~ 50 °C (32 ~ 122 °F) with SSD;
0 ~ 40 °C (32 ~ 113 °F) with HDD
(Thickness Max : 7.5mm )
-20 ~ 60 °C (-4 ~ 140 °F)
10 ~ 95% @ 40°C (non-condensing)
Operating 10 G Peak Acceleration (11 ms Duration), Follows IEC 60068-2-27
Operating random vibration test, 5 ~ 500Hz, 1Grms with HDD;
2Grms with SSD, following IEC 60068-2-64
Safety: CB, UL, CCC, BSMI
EMC: CE, FCC Class B, BSMI
419.70 x 269.00 x 59.20 mm
(16.52 x 10.59 x 2.33 in)
5.40kg (11.88lb)
PPC-3211W-P75A
21.5"
21.5" TFT LCD (LED backlight)
1920 x 1080
300 cd/m
2
16.7M
0.24825 x 0.24825 mm
89 (Left), 89 (Right),
89 (Up), 89 (Down)
5, 000
50, 000 hours
2 x 2.5" SATA bay (supports Intel
RAID); 1 x M.2 bay (size: 22 x 42 mm,
socket 2 B key, for storage only)
75W
0 ~ 50 °C (32 ~ 122 °F)
558.40 x 349.80 x 63.80 mm
(21.98 x 13.77 x 2.51 in)
7.67kg (16.87lb)
