INSTALLATION MANUAL
DIGIWAY PLUS
Connect the equipment to the Mains power using the appropriate cable ( 3 x 1,5mm
the profile and the backplate and avoiding being too tense and touching sharp edges. At the end of the installation, connect to
the ground cable provided with the electronic card ( yellow-green ) to the corrispondent faston of the cover.
scroll up / increases value
eSc - back to upper level
scroll DoWn / decreases value
It's possible to exclude the external switch using the jumper located on the internal
card of the left cap
cdvi.com
12
cdvigroup.com
electronic card layout and programming buttons
Battery
connector
Display LcD
monitor LeD's
19-way
terminal block
Jumper for external switch exclusion
Wiring diagram
ftc-S [ Stop ]
ftc [ re-open ]
Serial 7-way
connector terminal block
oK
external switch
not used
6 x 0.8 mm
2
6 x 0.8 mm
2
Internal external
radar radar
), passing it through the rear opening of
2
fuse
3,15a
fuse
1a
pe
connection
Jumper on
Jumper off
Switch Switch
excluded enabled
EN
Door aLWayS
open
Door free
fuLLy automatIc
