Step II allows you to set all the basic parameters of the operator, according to the type of door to automate

The submenu CONFIGURATION consists of 18 parameters.

Each parameter can have 2 or more values.

For each parameter there is a preset factory value. If the function FACTORY DEFAULT of the main menu is used, all the parameters

are reset to those values.

See the description of each parameter in the following table:

Parameter

Num. Doors

Sets the number of Doors

Electrolock

Enables electrolock and specify the type

Enables the opening Jolt : SHORT PULSE OF CLOSING BEFORE

Opening Jolt

OPENING. Usefull to unlock the electrolock in windy situations

Push & Open

Opens automatically the door with a short push.

Push & Close

Closes the door with a short push even in pause status.

Keeps the door closed in presence of wind which pushes the door. See

Wind Stop

ADVANCED SETTINGS to set the level of the closing force used.

Autoreclosing

Enables the automatic reclosing of the door

INTERNAL radar operating mode. If it's selected the option CLOSING the

Radar 'I' Mode

radar is excluded during the closing. This avoids the door to reopen for the

arm detection

EXTERNAL radar operating mode. If it's selected the option CLOSING the

Radar 'E' Mode

radar is excluded during the closing. This avoids the door to reopen for the

arm detection

Day / Night

Set the Night / Day mode. In Night mode the External radar is disabled.

Disabled access mode ( See paragraph Disabled

Disabled Mode

access settings)

Functions of the main command which can open, close and stop ( this will

Open Command

be the function assigned to the open button ( terminals 15-16 ) and to the

radio transmitter

Spring function: if the door is closed, it remains free and can be pushed

manually; once opened, the door will reclose after the pause time set.

Mode Spring

NOTE : In Spring mode the pause time is 1 sec. if the door is partly

opened and equal to the set value if the door is opened completely .

Overlap of the leaves ( in case of double doors ). In this case starts first

2 Doors Overlap

the MASTER leaf in opening and first the SLAVE leaf in closing. If the

parameter is DISABLED the leaves open and close simultaneously

Door Type

Leaf MASTER or leaf SLAVE ( in case of double doors )

Articulated or sliding arm. This parameter set the VELOCITY of the door

Arm Type

according to the arm type selected. (See Adjustments)

50% ARTICULATED ARM, 70% SLIDING ARM

Fire signal management. When this option is enabled the door operates

regularly only if the fire power V-/V+ is present. If the fire power falls down

Fire Signal

( for a fire alarm in progress) the door reacts according to the choice set in

the advanced sets options )

ATTENTION : Any change carried out needs a complete cycle ( open, pause, close ) or a system reset to be

implemented.
