Reset To Factory Default & System Reset - CDVI DIGIWAY PLUS Instructions For Installation, Use And Maintenance Manual

INSTALLATION MANUAL
DIGIWAY PLUS
Information
Display
M / S o
Master /
Opening
Slave
Action in progress
F Forward
R Reverse
K Brake
I Idle
Information
SW Release
Information
Counter
If the set-up of the parameters hasn't been successful, it's possible to recover the factory settings using the sub-menu Factory defaults
from the Main menu. After the completion of this function, all the parameters will be reset to the factory value. See each function to know
the corresponding value
Menu Main
Factory Defaults
Having reset the system to the factory settings, the operator can drive the door but without using the the acceleration and deceleration
values calculated during the Step III of Door Calibration. In order to revert to the previous operating mode it is necessary to repeat Step
III again. The door limits ( DOOR CLOSE and DOOR OPEN ) remain the same. The transmitters memory is completely erased, Master
transmitter included and reset to 1111 the System password for the partial counter.
It is possible to give a restart to the system, equivalent to a "power-off + power-on", using the option "System Reset" from the main menu.
After the system reset the LCD displays the sw release, the parameters condition and the free memory space for transmitters.
This function doesn't change the value of any parameter except for the currents ( I and i ) which will be re-calculated during the next 2
cycles.
MENU MAIN
System Reset
Display
Expert / Normal
LEGEND DISPLAY EXPERT MODE
O c C B
Open Closing Closed Obstacle
FMoOcCBXbsMiIUJ
P=-000.0 V=-00.0
Position (+/-)
P
WadoPlus v2.0a
dd/mm/yyyy
Counter
00000
factory Defaults
Reset to Factory
Defaults?
Are you sure?
Answer OK to proceed or ESC to exit without any action
System reset
Confirm
System Reset?
Are you sure?
Information
It's possible to change the information displayed on the LCD by setting the operating
mode EXPERT or NORMAL
In EXPERT Mode all the main parameters of the motion will be displayed according to
the following diagram:
1,2,3,4,5,f b s M
restart for
Obstacle type Stop Motor
obstacle
Speed: rpm/10
V
Gives the SW release number and date.
The absolute counter logs each cycle of the door ( OPENING +CLOSING). Its
value can be reset only by the factory.
i I U J/E
Opening Closing Opening
Electrolock
current current Jolt
