INSTALLATION MANUAL
DIGIWAY PLUS
Advanced Setting
16)
OD on Closing
Advanced Setting
17)
Approach speed
Advanced Setting
18)
Obst. detection %
Advanced Setting
19)
Min Open Speed
Advanced Setting
20)
% Min Open Speed
21) Advanced Setting
O.D. Cycle
Advanced Setting
22)
Test FTC
Advanced Setting
23)
Test FTC-S
Advanced Setting
24)
Test FTC Fail
Advanced Setting
25)
Test FTC-S Fail
Advanced Setting
26)
Low Energy
Advanced Setting
27)
Low Energy
cdvi.com
22
cdvigroup.com
After the detection of an obstacle during the closing the door will react in different way,
OD on Closing
Reopen according to the following settings:
•
•
•
It's possible to change the approach speed during the final closing.
Approach speed
5
This can be usefull if the door finds some friction in the last approaching motion where is
|||||||||||||||||......................
searching for the close position.
Default value = 5.
It's possible to change the percentage of the complete door trip after which the door
Obst. detection %
2%
doesn't detects an obstacle but assigns the stop to the close position.
|||||||||||||||||......................
Default value = 2%
It's possible to change the approach speed during the OPENING.
Min Open Speed
This can be usefull if the door finds some friction in the last approaching motion where is
5
|||||||||||||||||......................
searching for the open position.
Default value = 5.
It's possible to change the percentage of the complete open trip after which the keeps
% Min Open Speed
.2% the speed at the value set with the parameter "Min Open Speed".
|||||||||||||||||..................
Default value = 2%.
It's possible to set the type of cycle after an obstacle detection:
O.D. Cycle:
FAST : the door keeps the regular speed after the detection of an obstacle
Fast
SLOW : the speed of the door after an obstacle is slow.
It's possible to disable the test on the re-open photocell FTC:
ENABLED /
DISABLED
attentIon!!: If the test is DISaBLeD the operator must work in Low energy mode
otherwise it doesn't operate in compliance with the Standard en16005.
It's possible to disable the test on the stop photocell FTC-S:
ENABLED /
attentIon!!: If the test is DISaBLeD the operator must work in Low energy mode
DISABLED
otherwise it doesn't operate in compliance with the Standard en16005.
In case of malfunction of the safety photocells FTC it's possible to set the operating
STOP /
LOW ENERGY
mode: STOP / motion in LOW ENERGY
In case of malfunction of the safety photocells FTC-S it's possible to set the operating
STOP /
mode: STOP / motion in LOW ENERGY
LOW ENERGY
Diameter (m)
The sw calculates the minimum opening/closing time when the malfunction mode is set
1,2
|||||||||||||||||......................
at Low Energy, according to the doorset diameter ( in m) and weight ( in Kg ).
Weight ( Kg )
Sets the doorset weight in Kg.
120
|||||||||||||||||...................
Reopen : The door reopens and after the pause time recloses
Stop & Wait : The door stops and after the pause time recloses
STOP : The door stops: waits for a command to reopen and for a further
command to reclose.
