INSTALLATION MANUAL
DIGIWAY PLUS
!
The present document contains important precautions for the use and the operating
safety. Read carefully the instructions before commencing the installation
Keep this document even after installation.
This manual is intended for professional installers, adequately trained.
Installation and connections must be carried out in accordance with Good Working Practice and in compliance
with the current Regulations. Poor installation could be source of a health & safety hazard.
First check all of the existing door and frame structure - verify its integrity, stability and strength.
If necessary modify the structure in order to make it standard, being aware of all the possible problems which
could occur during normal use.
Verify that all the zones where there is a risk of crushing, dragging, shearing and other dangers, are protected by
electronic safety, safety freeboards or barriers.
This can be achieved if the distance does not exceed 8 mm. However, to avoid entrapment for the various parts
of the body, the following distances are considered sufficient:
Hand fingers> 25 mm
Foot> 50 mm
Head> 300 mm
Body> 500 mm
The forces developed by the complete system must comply with the current standards and, where this is not
possible,protect the zones with electronic safety devices.
Apply hazardous area notices required by the applicable regulations.
Before the actuator is connected, make sure that the plate details corresponds to those of the mains power and
that there is a differential circuit-breaker and an adequate protection against overcurrents on the supply side of
the system.
Fit a Dual Pole disconnection switch with contact opening gap of at least of 3 mm.
Interrupt the power supply before opening the cover of the actuator for any maintenance or repairing intervention.
Handling of electronic parts must be carried out wearing grounded antistatic bracelets to avoid any static
damage.
Servicing the actuator is of fundamental importance if the system is to operate correctly and safely.
Comply with the manufacturer's instructions described in this manual.
Only use genuine spare parts if replacements or repairs are required.
The motor manufacturer declines any responsability in the event of component parts fitted that are not
compatible with the safe and correct operation. The actuator must be installed only inside buildings
The manufacturer declines all liability for damage caused by assembly on the outside, without adequate
protection.
This product cannot be installed in places with an explosive atmosphere or in the presence of inflammable fumes
or gases.
Important precautIonS for the Safety
