1. Symbols used in this document

Warning
Page If these safety instructions are not observed,
it may result in personal injury.
10
10
Warning
11
These instructions must be observed for
12
explosion-proof pumps. It is advisable also to
12
follow these instructions for standard pumps.
12
If these safety instructions are not observed,
12
Caution
it may result in malfunction or damage to the
15
equipment.
20
20
Notes or instructions that make the job easier
Note
22
and ensure safe operation.
23
24

2. Scope of delivery

26
Grundfos Multilift MOG (one pump) and MDG (two pumps) lifting
26
stations are supplied complete with collecting tank, a sensor unit
27
with cable and one or two pumps with cable, connected to the
28
LC 221 controller. The controller includes a power supply cable
29
with plug.
29
An accessories bag containing the following items is also
30
included:
30
• 1 x installation and operating instructions
30
• 1 x Quick guide for controller menu
31
• 1 x oval discharge flange, 1 1/4" (MOG)
32
2 x oval discharge flanges, 1 1/4" (MDG)
32
• 1 x flexible hose, DN 70, and two clamps to connect venting
33
pipe
33
33 • 2 x screw and expansion anchor for tank fixation
33
• 3 x screw and washer for fastening a pipe plug in the inlet disk,
if required
34
• 1 x socket seal, DN 100
35
35
• 1 x socket seal, DN 50, for diaphragm pump connection or
35
inlet, DN 50.
35
The lifting stations are supplied complete with one or two pumps
35
and a controller.
37
37
Lifting station
MOG, one-pump lifting station
MDG, two-pump lifting station
Controller
LC 221.1
LC 221.2
