Switch S3 is used to control the sequence in which LEDs D2, D3, and D4 flash,
when running the Demo program.
2. Connect and apply power to the development board as described in
Development Board
Caution:
Do not apply power to the development board unless the USB Smart
Cable is connected to the host PC and to the development board's DBG
Port P3.
3. Run the ZDS II software. By default, the ZDS II is located in the Start menu under
→
Programs
ZiLOG
<version_number>
4. Select Open Project from the File menu. The Open Project dialog box appears.
Note:
The sample used in the following steps is in the 'C' programming language.
An assembler version of the Quick Start sample is located in the
samples\Assembly
5. Browse to the
Samples
default in below path:
c:\Program Files\ZiLOG\ZDSII_ZNEO_<version_number>\samples\
QuickStart
6. Select the
Z16F2800100ZCOG.zdsproj
program screen opens (see
To view the project source files, double-click the Project Files folder on left side of
the IDE interface. Double-click an individual file to open that file in the ZDS II file
editor.
Note:
The following figures are for reference only. The results may vary slightly
due to configuration differences or later software revisions.
QS005703-0908
®
ZNEO
Series of Microcontrollers Development Kit
on Page 2 through Page 8.
ZDS II
ZNEO
folder.
folder for the
Z16F2800100ZCOG.zdsproj
Figure 3
on page 10).
<version_number>
file and click Open. The initial ZDS II
Setting Up the
:
→
ZDS II
ZNEO
file, located by
Page 9 of 18
