ZiLOG ZNEO Series Quick Start Manual page 5

2. DemoShield provides several installation choices. Select Install Zilog Developer
Studio to install now. You can install other software and accompanying documenta-
tion later.
3. Follow the instructions on the screen to complete the installation.
Installing USB Smart Cable
Follow the instructions below to install the USB Smart Cable and associated driver
software:
Windows Vista-32
Follow the steps below to install the USB Smart Cable for Windows Vista-32:
1. Connect the USB Smart Cable to the host PC. The Found New Hardware wizard is
displayed.
2. Select Locate and install driver software (recommended). The User Account
Control window is displayed, click Continue. The Driver Software Installation
window is displayed, and then the Found New Hardware-USB Smart Cable dialog
box is displayed.
3. Select I dont have the disc. Show me other options.
4. Select Browse my computer for driver software (advanced).
5. Browse to one of the following driver directory:
<ZDS II Installation Directory>\device drivers\USB\x32
<ZDS II Installation CD>\device drivers\USB\x32
6. Click Next. The Windows Security dialog box is displayed.
7. Select Install this driver software anyway.
8. When the software has been installed successfully, click Close.
QS005703-0908
®
ZNEO Series of Microcontrollers Development Kit
Page 5 of 18
