ZNEO Series of Microcontrollers Development Kit
In ZDS II, select the Project → Settings menu item. In the Debugger tab of the
•
Project Settings window, in the Target section, verify that the Z16F2800100ZCOG
option is selected. Verify that the drop-down menu in the Debug Tool section is set to
USBSmartCable.
Click the Setup button in the Debug Tool box and verify that the serial number for the
USB Smart Cable interface is present. If the serial number is missing, reinstall the
USB Smart Cable driver software.
• In ZDS II, click the Rebuild All
errors.
• Verify that the development board is not currently running any code — no LEDs
should be blinking.
• In ZDS II, click the IDE Reset
board and download code to it.
• Open the Windows Hyperterminal application (located in your Accessories program
group) and connect a DB9-to-DB9 cable between your host PC and console port P2 of
the development board. Set the communication settings to 57600 8 bits, no parity, one
stop bit. This is noted on
•
Click the Go
terminal should display the 'Hello World!' message.
If you perform these steps and cannot get the demo code to run, contact Zilog Technical
Support at www.zilog.com.
