UM0068
1

Getting started

1.1

System requirements

In order to use the ST7MDTULS-EVAL with the Windows operating system, a recent version
of Windows, such as Windows 98, Windows Millennium, Windows 2000, or Windows XP
must be installed on the PC.
The version of the Windows OS installed on your PC may be determined by clicking on the
"System" icon in the Control Panel.
Caution: When running the HID evaluation board applet provided in the package, verify that the
correct version of the HID.dll file is installed:
Windows 98: HID.dll - Version 4.10.1998
Windows 98 SE: HID.dll - Version 4.10.2222
Windows Millennium: HID.dll - Version 4.90.300.1
Windows 2000: HID.dll - Version 5.00.2134.1
Windows XP: HID.dll - Version 5.1.2600.0
1.2

Package contents

The USB evaluation low-speed board package includes the following items:
Hardware content
–
–
Software content
–
–
–
Documentation
–
–
–
1.3

Software installation

Run USBDemonstrator.exe to install the PC HID demonstrator, and follow the on-screen
prompts to complete the installation.
Two ST72 Low-speed USB microcontroller devices:
ST7262xxx devices in SDIP42 package
ST7263Bxx devices in SDIP32 package
Both devices are FLASH devices allowing up to 100 reprogramming cycles. They
are delivered already programmed with the demonstration firmware.
One evaluation board
PC executable software for demonstrating HID transfers.
ST7 firmware (C source code) for the ST7262xxx devices
ST7 firmware (C source code) for the ST7263Bxx devices
USB library 4 x Interface documentation.
ST7262 and ST7263Bxx datasheets
Application note AN1325
Getting started
5/15
