UM2407
5
Quick start
The STM32H7 Nucleo-144 board is a low-cost and easy-to-use development kit, used to
evaluate and start a development quickly with an STM32H7 Series microcontroller in
LQFP144 package.
Before installing and using the product, accept the Evaluation Product License Agreement
from the www.st.com/epla web page. For more information on the STM32H7 Nucleo-144
and for demonstration software, visit the www.st.com/stm32nucleo web page.
5.1
Getting started
Follow the sequence below to configure the Nucleo-144 board and launch the
demonstration application (for components location refer to
1.
Check jumper position on the board:
Jumper
JP1
STLK_RST
JP3
T_NRST
JP5
VDD_MCU power selection
JP4
IDD measurement
JP2
Power source selection
2.
For the correct identification of the device interfaces from the host PC and before
connecting the board, install the Nucleo USB driver available on the
www.st.com/stm32nucleo website.
3.
To power the board connect the STM32H7 Nucleo-144 board to a PC with a USB cable
'Type-A to Micro-B' through the USB connector CN1 on the ST-LINK. As a result, the
green LED LD6 (PWR) and LD4 (COM) light up and the red LED LD3 blinks.
4.
Press button B1 (left button).
5.
Observe the blinking frequency of the three LEDs LD1 to LD3 changes, by clicking on
the button B1.
6.
The software demonstration and the several software examples, that allow the user to
use the Nucleo features, are available at the www.st.com/stm32nucleo web page.
7.
Develop an application, using the available examples.
Table 4. Jumper configuration
Definition
OFF
ON
ON [1-2] (default)
ON [2-3] (optional)
ON
ON [1-2]
UM2407 Rev 1
Figure
Position
VDD_MCU supplied with 3V3_VDD
VDD_MCU supplied with 1V8_VDD
MCU current measurement
5V_USB_STLK (from ST-LINK)
Quick start
4):
Comment
-
-
11/48
47
