DLT-V8315: AC variant, maximum equipment level (optional)
Pin assignment (standard)
Power supply
DLT-V8315
Audio MIC PWR out
COM1, COM2
2 x RSMA (optional)
RJ45
USB2, USB1, USB0
Expansion interfaces package 1 (optional)
D I/O
RJ45
Expansion interfaces package 2 (optional)
CAN
D I/O
RJ45
18
100 up to 240 VAC
Voice kit
Serial interfaces
Remote WLAN antenna
LAN Ethernet 10/100/1000 MBit/s
USB 2.0 interface (HI-SPEED™), bootable
Digital In/Out
LAN Ethernet 10/100/1000 MBit/s
CAN interface
Digital In/Out
LAN Ethernet 10/100/1000 MBit/s
