P-Scope Quick Start Guide – Rev. AP5
Top level buttons and their functions
There are a series of top level buttons on the P-Scope graphical interface. These are described in the
following table:
Button
Capture Control
Frame Selector
Frame Data Chart
Detailed Data
Video Frame
Viewer
Frame # Chart

Status Bar

At the bottom of the P-Scope main window is a status bar that provides connection status. It also provides
a statement about the time for capture once you have initiated a data capture; e.g. "Please wait."
Function
Opens up the Capture Control window which enables you to capture data and
set up the triggers for capturing the data.
Opens up the Frame Selector window which enables you to select frames for
viewing.
Opens up the Frame Data window which enables you to view frame protocol
statistics and access lower level (more detailed) data.
Opens up the Detailed Data window which enables you to view the details of
each transaction for all lines in a previously selected frame.
Enables you to see the video pattern that is active (sent in from the source) for
a particular frame.
This button appears once you have accessed a specific frame from the Frame
Data Chart window. When it is present, clicking on it will open up the Frame #
Chart window which enables you to view protocol statistics for each line in the
frame. It also enables you to access the Detailed Data window to view lower
level (more detailed) data.
P/N 68-00214
