P-Scope Quick Start Guide – Rev. AP5
Capture Slide Bar
Buffer %
Entry Field
Capture Button
Controls
End Indicates that the data that is captured, and
stored for later analysis, ends at the trigger point
and extends earlier in time to an amount of
frames determined by the Capture Buffer %
setting.
0 – 100% Enables you to set a percentage of the
maximum number of frames for capture and
storage by sliding the bar to a particular value.
You can capture up to about 1150 frames at
576p/480p and about 204 frames at 1080p.
0 – 100% Enables you to explicitly enter a percentage of
the maximum number of frames for capture and
storage. You can capture up to about 1150
frames at 576p/480p and about 204 frames at
1080p.
Start Capture Data Causes the P-Scope to begin capturing data.
Stop Data Capture Causes the P-Scope to stop capturing data.
