Quantum Data HDMI P-Scope Quick Start Manual page 32

P-Scope Quick Start Guide – Rev. AP5
Capture Button
Controls
3. Set the Capture Buffer % to control what percent of the capture buffer you want to capture. You can capture
up to about 1150 frames at 576p/480p and about 204 frames at 1080p.
4. Click on the Capture Data button.
The P-Scope will capture the data. The cursor becomes an hour glass icon to indicate that the capture is in
progress. When the P-Scope is done capturing data, its windows will be reconfigured as shown below with
the Frame Selector window on top and the Frame Data Chart window occupying the lower portion of the
window.
and about 204 frames at 1080p.
Start Capture Data Causes the P-Scope to begin capturing data.
Stop Data Capture Causes the P-Scope to stop capturing data.
P/N 68-00214
