P-Scope Quick Start Guide – Rev. AP5
Save (Icon)
Enables you to save the transactions to a file for distribution to others or for later analysis.
All Packets Enables you to toggles between seeing packets or just seeing errors.
(button)
Delta mode
Enables you to view the timestamps in relation to the selected transaction. The default is
Cumulative which shows the timestamps starting from a reference point of the first
transaction.
Filters Enables you to view specific data types only (most of these are not currently used):
(checkboxes)
Packets The Packets window is a scrolling window that provides the following information:
Details Panel Shows the data, for the highlighted line, parsed out in human readable text.
Data Panel Shows the data, for the highlighted line, in hex form.
Status Bar The status bar indicates the following:
EDID – Not currently used.
DDC/CI – Not currently used.
HDCP – Not currently used.
CEC – Not currently used.
Events – Not currently used.
Others – TMDS data.
Frame – Not currently supported.
Line – Not currently supported.
Pixel – Not currently supported.
Timestamp – Provides the timestamp for each transaction since the beginning of the
captured data.
Events – Not currently supported.
Dir[ection] – Indicates the direction of the transaction, source to sink or sink to source.
Source – Indicates the general class of data, e.g. TMDS, DDC, CEC.
Type – The type source data. (Not fully implemented.)
Details – Indicates the type of data by name, e.g. Audio Sample.
Connection status
Packet count
