Dimensions- Enclosure - Fluidwell F Series Manual

4.3.

DIMENSIONS- ENCLOSURE

Aluminum enclosures:
130 mm (5.12")
30mm 30mm
HA
PG9
M20 x 1,5
30mm 30mm
HM
M16 x 1,5
M20 x 1,5
HN
M20 x 1,5
25mm
HO
M20 x 1,5
29.1 mm (1.15")
HB
31 mm
(1.22")
75 mm (2.95")
PG9
M16 x 1,5
25mm
M20 x 1,5
Fig. 6: Dimensions Aluminum enclosures.
HF073TEN_v0403_05 Atex_IECEx_CSA_FM
112 mm (4.40")
12mm 12mm
24mm 24mm
6 x M12
36mm 36mm
1/2"NPT
0.12" 0.12"
3x 1/2"NPT
23 15 15 23
mm
4x M20 x 1,5
115 mm (4.53")
Page 19
HP
HT
HU
HV
HZ
