UNDER
41
SET ALARM
42
The functions below will only effect the optional LED-backlight.
BACKLIGHT
(OPTION)
43
BACKLIGHT ALARM
(OPTION)
44
BRIGHTNESS
(OPTION)
45
When used with the internal battery option, the user can expect reliable measurement over a long
period of time. The F073-T has several smart power management functions to extend the battery life
time significantly. Two of these functions can be set:
LCD NEW
51
BATTERY-MODE
52

4 - DISPLAY

The small 8mm digits can be set to display:
height - percentage - off
This function determines if the level alarm values can be set at both
Operator level and SETUP-level or SETUP-level only.
If SETUP has been selected, the alarm values are still visible for the
Operator but cannot be changed.
If a LED backlight has been supplied, the color can be selected.
Following selections are available:
OFF - GREEN - AMBER
In case the F073-T generates a level alarm, the backlight can be set to
change to red. Following selections are available:
during level alarm the color is according to setting 43
OFF:
during level alarm the color is red.
ON:
during level alarm the color flashes red and the color as
FLASH:
set with
The brightness of the backlight can be set in following range:
1 - 5
1 is minimum and 5 is maximum brightness.

5 - POWER MANAGEMENT

The calculation of the display-information influences the power
consumption significantly. When the application does not require a fast
display update, it is strongly advised to select a slow refresh rate.
Please understand that NO information will be lost; the input signal will be
processed and the output signal will be generated in the normal way.
The following can be selected:
Fast - 1 sec - 3 sec - 15 sec - 30 sec - off.
Example battery life-time:
battery life-time with a FAST update: about 3 years.
battery life-time with a 1 sec update: about 5 years.
Note: after a button has been pressed by the operator - the display
refresh rate will always switch to FAST for 30 seconds. When OFF is
selected, the display will be switched off after 30 seconds and will be
switched on as soon as a button has been pressed.
The unit has two power modes: operate and shelf.
After shelf has been selected, the unit can be stored for several years; it
will not process the sensor signal; the display is switched off but all
settings are stored. In this mode, power consumption is extremely low.
To wake up the unit again, press SELECT twice.
HF073TEN_v0403_05 Atex_IECEx_CSA_FM
43.
