Height; Alarm - Fluidwell F Series Manual

Page 14
If desired the height of the level column can be calculated and displayed.
MEASUREMENT UNIT
21
DECIMALS
22
SPAN
23
OFFSET
24
With these settings, it is determined how the level will be monitored and the functionality of the
transistor output (terminals 7-8) be determined.
EMPTY
31
ALARM LOW LEVEL
32
ALARM HIGH LEVEL
33
DELAY TIME ALARM
LOW LEVEL
34
DELAY TIME ALARM
HIGH LEVEL
35
ALARM OUTPUT
TRANSISTOR / RELAY
36

2 - HEIGHT

21 determines the measurement unit for height.
SETUP
The following units can be selected:
mm - cm - m - mtr - inch - ft - mmwk - mmwc - cmwk –
cmwc - mwk - mwc - inwc - ftwc - mbar - bar - psi -
no unit.
Alteration of the measurement unit will have consequences for operator
and SETUP-level values.
Please note that the Span (
calculation is not done automatically.
This setting determines for height the number of digits following the
decimal point. The following can be selected:
00000 - 1111.1
With the span, the sensor signal is converted to a height.
The span for height is determined on the basis of the selected
measurement unit at 100% signal.
The more accurate the span, the more accurate the functioning of the
system will be :
Example Calculating the span for height
Let us assume that the sensor generates 100% signal at
a level of 2,481.3 cm, the selected unit is "cm".
The span is 2481.3
Enter 2481.3 for
Enter here the "not measured" height which is below the sensor.
Also, a negative offset can be entered: to do so press the middle and right
button simultaneously.

3 - ALARM

When the level is zero (or the offset value
ignore or disable the level monitoring. The following settings can be
selected:
in case of a low-level alarm and zero level, it will switch
DEFAULT:
the alarm output and indicate the alarm on the display.
in case of a low-level alarm and zero level, it won't switch
NO RELAY:
the alarm output but will indicate the alarm on the display
only.
in case of a low-level alarm and zero level, it won't switch
IGNORE:
the alarm output and nothing will be indicated on the
display.
The low alarm is set with this setting. An alarm will be generated as long
as the actual level is below this value. Entering 0.0 disables this function.
The high alarm is set with this setting. An alarm will be generated as long
as the actual level is above this value. Entering 0.0 disables this function.
An alarm generated by
SETUP
period. If the actual level is still incorrect after this delay time, then an
alarm will be generated.
An alarm generated by
SETUP
period. If the actual level is still incorrect after this delay time, then an
alarm will be generated.
A transistor output is available to transmit alarm conditions. Assign with
this function the type of alarm to be transmitted:
hi - lo - hi_lo (both alarms) - off (no alarm)
HF073TEN_v0403_05 Atex_IECEx_CSA_FM
23) has to be adapted as well; the
SETUP
- 2222.22
23.
SETUP
15), then it is possible to
SETUP
32 low can be ignored during X-time
33 high can be ignored during X-time
