11. Disconnect the tow cable and option connectors.
12. Slide the electronics chassis completely out of the housing and lay it on a clean flat surface.
13. If it is desired to reconnect the tow cable and option connectors for troubleshooting and test
purposes, place the electronics chassis alongside the housing and reconnect the connectors.
With the tow vehicle powered, high voltages that can cause injury or
death are present on the electronics chassis. Use caution when working
on the electronics chassis with the tow vehicle-powered.

5.2.2 Reassembling the Tow Vehicle

Before reassembling the tow vehicle, replace the two O-rings on the end cap. When installing a new O-
ring, first clean the O-ring surfaces on both the housing and the end cap with the paper towel. Then apply
a light coating of silicone lubricant to the new O-ring around its entire surface before installing it.
To reassemble the tow vehicle, reverse the disassembly procedure. However, when reassembling the end
cap to the housing, align it first with + the locating pin on the housing.
WARNING!
5-7
