Optional Responder

The optional Responder board inputs a responder trigger internally from the tow vehicle or the topside
processor. When triggered, the Responder board drives up to 200 watts of power into an acoustic
transducer mounted in the nose of the tow vehicle. The transmit frequencies are 24 to 28 kHz chirp or 27-
kHz CW.

2.3 Cables

Outline drawings of the optionally available Kevlar reinforced, and armored tow cables, tow cable adapter,
and test cable can be found in sub-section

2.4 Optional Depressor Wing

The specifications for the optionally supplied Depressor Wing are shown in
Size:
Weight in air:
Weight in saltwater:
Depressive force:
Depression angle:

2.5 Mechanical Drawings

Mechanical drawings for the 4200 Towfish Configurations are shown below:
1.1.1.1APPENDIX A:
61.0 cm (24 in.) long
72.4 cm (28.5 in.) wide
34.9 cm (13.75 in.) high
12.7 kg (28 lb)
7.7 kg (17 lb)
85 lb @ 5 knots
255 lb @ 10 knots
590 lb @ 15 knots
0°, 5° or 10°, user-adjustable

Table 2-3: Depressor Wing Specifications
