3.5 Topside Processor Controls and Indicators

The following sub-sections describe the controls and indicators for the three 4200 Series topside
processor options. Labeled photos of these panels are provided in
F
3-2
for the Rack Mount Topside,
IGURE
Digital Link.

3.5.1 4200 Rack Mount Topside Processor Controls and Indicators

The 4200 Rack Mount Topside Processor includes controls and indicators on the front and back panels, as
F
3-1and
F
shown in
IGURE
as these are unique to the Rack Mount processor option.
The 4200 Rack Mount Topside Processor controls and indicators are the following:
POWER:
SYSTEM POWER:
FISH POWER:
(switch)
RESET:
FISH POWER:
(indicator)
HDD:
SYSTEM POWER:
(indicator)
4200 SIDE SCAN SONAR SYSTEM USER HARDWARE MANUAL
F
3-3
for the Portable Topside, and
IGURE
3-2. Note the DVD and removable 1-TB drives located on the front panel,
IGURE
Rocker switch. Switches AC power to the 4200 Rack Mount Topside
Processor. This switch can be left in the ON position at all times.
Push-button toggle switch. Turns the 4200 Rack Mount (switch) Topside
Processor ON or OFF.
Push-button toggle switch. Applies power to the tow vehicle.
Momentary push button switch. Resets the 4200 Rack Mount Topside
Processor.
Red indicator. Illuminated when power is being applied to the tow
vehicle.
Yellow indicator. Flashes when a hard drive on the 4200 Rack Mount
Topside Processor is being accessed.
Green indicator. Illuminated when the 4200 Rack Mount Topside
processor is on.
F
3-1
and
IGURE
F
3-4
for the 701-DL
IGURE
0004842_REV_N
3-4
