5.8 Part Numbers for Major Tow Vehicle Components

The major tow vehicle components and their part numbers are listed below:
DESCRIPTION, PART NUMBER
COMPASS MODULE, 0008518
KONTRON CPU ASSY, 0012666
ASSY AMP, BD 0006125
SSAC BD, 0006163
SONAR/IDE BD, 0006102
DSL MODEM, 0006104
POWER DIST BD, 0006134
SHEAR PIN 5/16", 0006301
100/400 RX XDUCER, 0003029
100/400 TX XDUCER, 0003030
300/600 RX XDUCER, 0008228
300/600 TX XDUCER, 0008229
300/900 TX XDUCER, 0007462
300/900 RX XDUCER, 0007461
100/400 RX/TX SP XDUCER 0003031
300/600 RX/TX SP XDUVER 0008770
300/900 RX/TX SP XDUCER 008772
TAIL FIN, 350-0000742-0300 (0008146)

Table 5-5: Part Numbers for Major Tow Vehicle Components

5.9 Tow Vehicle Outline Drawings

Outline drawings of the tow vehicle and the tow vehicle tail fins are found in sub-section
V O D
EHICLE UTLINE RAWINGS
4200 SIDE SCAN SONAR SYSTEM USER HARDWARE MANUAL
T/R BD, 0006173
T/R BD, 0007433
T/R BD, 0008514
DDC BD, 0007432
100/400 300/600 300/900
X X X
X X X
X X X
X
X
X
X
X X
X X X
X X X
X X X
X X X
X
X
X
X
X
X
X X X
5-20
4200-SP
X
X
X
-
-
-
-
-
-
-
-
X
X
X
