3.3.1
Gear Reducer Breather
• To avoid the risk of having high pressure build-up in the reducer (gear box), a reducer breather should
be installed.
• Failure to install the breather may lead to oil leakage from the seal, which will damage the reducer.
All Gear Head operators are supplied with a Reducer Breather. The breather is not mounted at the factory in order to
avoid leakage during handling of the reducer.
Unscrew the plug
1
Plug
For technical support, please call 1-800-361-2260 or visit
9
CAUTION
Place the breather with the reducer elbow
2
Reducer
Breather
Breather
Elbow
(facing up)
Drain
www.manaras.com
Tighten the reducer elbow
and angle upwards.
Screw the reducer breather
in the reducer elbow.
for more information
