1.3.2 Brake Adjustment
The brake is factory set, however, after extensive use the brake may need to be adjusted.
Remove brake cover
1
Screws
Cover
Adjust solenoid gap
3
Pull the lever to adjust the gap between
the plunger and solenoid body.
Tighten pivot nut
4
Pivot
Nut
6
Re-install brake cover
For technical support, please call 1-800-361-2260 or visit
37
Screws
Lever
Recheck the gap
measurement.
Loosen pivot nut
2
Pivot
Nut
Gap must be between 1/4" and 3/8".
Solenoid
Body
Check brake adjustment
5
Lever
www.manaras.com
Plunge
r
Manually push the
lever and verify that
the brake drum
rotates when the
hoist is activated.
for more information
Lever
