To 5 Hp - Manaras Opera MGH Installation Instructions Manual

1.2

2 to 5 HP

SUPPLY VOLTAGE...............................208, 460, 575 V
CONTROL VOLTAGE............................24 V
MOTOR.................................................Continuous duty 2, 3, 5 horsepower
OPERATOR OUTPUT SPEED..............43 RPM
NET WEIGHT (Operator only)...............137 Lbs (62 Kg)
STANDARD WIRING TYPE..................C2 (momentary contact to open/stop and constant-pressure-to-close)
APPLICATION.......................................Very heavy duty worm gear for sectional doors, rolling doors and grilles
DUTY.....................................................25 cycles/hour or >80 cycles/day
Table 2 - Operator Selection Guide 2 to 5 HP
Rolling Doors
Insulated 16 ga
HP
Steel Steel
2 451 613
3 620 830
5 * *
* Consult Factory
For technical support, please call 1-800-361-2260 or visit
class 2 transformer, 2 amp fuse type ACG
AC
Figure 2 - MGH Dimensions 2 to 5 HP
Maximum Area in Square Feet (general guideline)
Steel Grilles
Alu. Door
20 ga
22 ga Steel
Steel
660
890
*
5
three-phase
AC
Steel
Alu. Grilles
Steel
18 ga
24 ga
18 ga
20 ga
ins.
Steel
ins.
560 620
830 870
* *
www.manaras.com
Sectional Doors
Wood
Alu. Steel
Steel 20 ga,
22 & 24 ga
22 & 24 ga
ins.
660
910
*
for more information
Fiber
Glass
