1.3
Band Brake Maintenance
• Be sure that the main power is OFF before performing any changes on the operator.
• Always return the door to fully closed position before performing any maintenance to the brake.
1.3.1
Changing a Brake Band
The brake band is preformed at the factory. Please insert the brake band carefully around the brake drum.
Remove brake cover
1
Screws
Cover
Replace band brake
3
Band Brake
Lever
Push the lever to reduce the tension when
removing or installing the band brake.
See brake adjustment
5
on next page
For technical support, please call 1-800-361-2260 or visit
WARNING
To reduce the risk of SEVERE INJURY or DEATH to persons:
NOTICE
Screws
36
Remove link locking plate and used band brake
2
Push or
pull to
remove
Band Brake
Place link locking plate
4
Be sure that the
link locking plate is
securely fastened
on the two pins.
www.manaras.com
for more information
