4.3
Operating Mode
This operator has a floor level hoist engagement lever to:
disconnect the door from the electrical motor
–
release the brake
–
engage the manual hoist mechanism, see Figure 12
–
1. Engagement
Pull chain on either side
to operate door.
For technical support, please call 1-800-361-2260 or visit
Chain Keeper
Pull the handle and
attach the disconnect
chain to the chain
keeper for manual
operation.
2. Manual Mode
Figure 12 - Hoist Engagement and Hoist Operation
12
Disconnect Chain
4. Return to Electrical Mode
Release the tension from
the disconnect chain to
return to electrical mode.
Handle
3. Storage
Follow the 3 steps shown below to
attach the chain (when not in use)
to the chain keeper.
www.manaras.com
for more information
