Quick Fix Instructions

Table 10 - Basic Troubleshooting Guide ~ from floor level
Symptom
Door doesn't respond
to any command
Door doesn't not
respond to "Close" or
radio commands
When pressing "Open"
button, door opens
~1-2 ft, then stops and
reverses
Door doesn't respond
to any radio command
Timer to Close doesn't
close the door
Timer to Close closes
the door after being
suspended
For technical support, please call 1-800-361-2260 or visit
Possible Cause
 Chain hoist is in engaged position, if applicable.
(LED D9 is OFF)
 Disconnect chain is in engaged position, if
applicable. (LED D9 is OFF)
 "Stop" button is stuck. (LED D9 is OFF)
 No power supply. (LED D2 is OFF)
 Photo cells are not properly aligned or are
obstructed.
 Loop is obstructed (presence of metal).
(LED D10 is ON)
 Mechanical door lock is engaged.
 Verify if the rubber seal at the bottom of the
door is frozen to the ground (winter time).
 No power supply. (transmitter light is OFF)
 Poor radio control range.
 Photo cells are not properly aligned or are
obstructed.
 Timer to Close has been suspended
accidentally for ONE cycle.
 Timer to Close has been reactivated
accidentally.
33
➔ Return the chain to its neutral
position (electrical mode). Refer to
p.12 for further details.
➔ Release tension from the
disconnect chain and secure the
chain keeper. Refer to p.12 for further
details.
➔ Press and release the "Stop"
button on the wall station several
times.
➔ Verify the incoming power line
from the main breaker, making sure it
has not tripped or blown a fuse.
➔ Clear the obstruction or re-align
photo cells.
➔ Clear the obstruction.
➔ Release the door lock.
➔ Clear ice and free the rubber seal
at the bottom of the door.
➔ Replace transmitter's battery.
➔ Bring the radio transmitter closer
to the operator.
➔ Clear the obstruction or re-align
photo cells.
➔ Timer to Close will return to
normal after the door has been fully
closed. Refer to p.25 for further
details.
➔ To suspend the Timer to Close,
close the door completely. Then
press the "Stop" button 3 times and
then press the "Close" button 3 times.
Refer to p.25 for further details.
www.manaras.com
Fix Problem
for more information
