Using AIT Data Cartridges

AIT is the only tape to incorporate the unique Memory-In-Cassette (MIC) feature. The
MIC feature reduces file access time and expedites the operation of the drive.
Top of the AIT
cartridge
indicated by
the clear
plastic
window
Bar code label
Figure 3-5 An AIT cartridge, left, and the DCM loaded with cartridges.
Insert the AIT data cartridge in the DCM with the cartridge window facing the top of
the magazine. Correctly installed, the data cartridge snaps into the tape slot.
Remove the data cartridge by grasping the cartridge and pulling it straight out of the
DCM.
Chapter 3. Using the Spectra 2K Library
Cartridge door
Holes to
the left
21
Top of the DCM
Bottom of the DCM
