Javad TRIUMPH-3 Start Manual page 2

munication between the receiver and an external device. The Ethernet port allows connect-
ing a local network.
The bottom 3/8-16 thread connector allows mounting TRIUMPH-3 on the monopode.
Ethernet port
TRIUMPH-3 START GUIDE
The power port is used to connect the re-
ceiver to an external power source and to charge
the batteries (Input voltage: +10...30 VDC).
The USB port is used for high-speed data transfer and com-
USB port USB port MicroSIM slot MicroSD slot Power port
2
To turn ON the receiver
press and hold for 1-3 sec-
onds the power button. To
turn OFF the receiver, press
and hold the power button
2-5 seconds or until LEDs are
off and then release the button.
The Bluetooth and WiFi buttons
allow turning on/off the Bluetooth
or WiFi modules. The Record button
starts/stops data recording.
