Appendix A: Freeze Dryer Components
2.5L -50C Models (70020xxxx)
2.5L -84C Models (71020xxxx)
Item -50C -84C
1 X
X
2
3 X
X
X
4 X
X
5 X
6 X
7 X
8 X
9 X
10 X
11 X
12 X
13 X
14 X
15 X
16 X
17 X
18 X
19 X
20 X
X
21
X
22 X
X
X
X
23
X
X
X
X
24 X
25 X
26
54
Part No.
7395800 Lid Gasket
7395801 Lid (Acrylic)
X 7207500 Lid Assembly, Stainless Steel (includes lid gasket
7395800)
X 7953802 Motor Fan, 115V
X 7953803 Motor Fan, 230V
X 7591805 Compressor, 115V, 60Hz
X 7591806 Compressor, 230V, 50Hz
X 7591807 Compressor, 230V, 60Hz
X 7316600 Display Assembly
X 7337300 Gasket, Display
X 7337400 Panel, Control
X 7336900 Label, Control Panel
X 7346400 Control Panel Assembly (Complete)
X 7335200 Drain Fitting (Coupling Body)
X 7335300 Drain Fitting (Coupling Insert, 3/8 Barb)
X 7337100 Retaining Ring, Drain Fitting
X 7337000 Lanyard, Drain Fitting
Machine Screw, 8-32 x 3/8" long
X 1889406
X 7429700 Moisture Sensor
X 7373450 Vacuum Hose
X 7403800 Filter, Female Luer-Lok
X 7403700 Luer, #10-32 Male
X 7432700 Vacuum Control/Bleed Valve
X 7362300 Vacuum Sensor
7330400 Electrical Panel Assembly 115V
7330401 Electrical Panel Assembly 230V
X 7330402 Electrical Panel Assembly 115V
X 7330403 Electrical Panel Assembly 230V
X 7515302 Temperature Sensor
X 1336400 Power Cord 115V 60Hz US
X 1338002 Power Cord 230V 60Hz US
X 1332601 Power Cord 230V 60Hz Saudi
X 1336500 Power Cord 230V 50Hz EU
X 1332701 Power Cord 230V 50Hz China
X 1332601 Power Cord 230V 50Hz UK
X 1345701 Power Cord 230V 50Hz India
X 7361100 Wire Harness, IOB Control
7361200 Wire Harness, Power
X 7361201 Wire Harness, Power
X 7419300 Baffle Collector
