End Point Detection (optional accessory)
An alert will be activated when the primary drying phase end point has been
detected for any of the active flask sensors connected to the End-Zone end point
detection accessory.
Shelf Temp Variation (optional accessory)
If a Tray Dryer or Heated Product Shelves accessory is connected to the Freeze
Dryer this alert will be activated if the shelf temperature varies more than ± 3°C
from the Shelf Temp Set Point.
Shelf Temp Set Point (optional accessory)
If a Tray Dryer or Heated Product Shelves accessory is connected to the Freeze
Dryer this alert will be activated if the shelf temperature stabilized without
reaching the Shelf Temp Set Point.
Power Fail (optional accessory)
If a Tray Dryer or Heated Product Shelves accessory is connected to the Freeze
Dryer this alert will be activated if a power failure occurs to the accessory.
Program Complete (optional accessory)
If a Tray Dryer or Heated Product Shelves accessory is connected to the Freeze
Dryer this alert will be activated when the last step of a running program has been
completed.

Copy (export) a Data Log File

Data Log Files can be copied (exported) to a USB flash drive via the USB port on
the left side of the Freeze Dryer. The file will be exported as a "comma separated
values" file (.csv file extension), which can be easily opened with a spreadsheet
application program for data analysis and graphing. To copy a file:
1. Insert USB flash drive into the Freeze Dryer USB port
2. Go to Data Logging screen
3. Select the file that you want to copy by pressing the Data Log File name
4. Press the Copy button
Downloading Data Log Files via Ethernet
Data log files that are stored in the Freeze Dryer can be downloaded via an
Ethernet connection. In order for this to be possible, a working Ethernet
connection must first be established. The following steps must be completed:
1. An Ethernet cable must be connected to the Ethernet port on the back of the
Freeze Dryer and to a Local Area Network (LAN) with working internet
service.
2. The proper settings must be entered into the Settings>Network screen to
establish a valid network connection (see description of Network screen in
Chapter 4).
