Freeze Dryer Components

Verify that the components listed below are present and undamaged.
(1) Freeze Dryer
(1) Collector Chamber Lid Assembly
o
o
2.5L 4.5L
1 1
1 1
1 1
2 2
1
1
If you did not receive one or more of the components listed for your Freeze Dryer,
or if any of the components are damaged, contact Labconco Corporation
immediately for further instructions.

Setting Up Your Freeze Dryer

After you verify receipt of the proper components, move your Freeze Dryer to the
location where you want to install it. Then, follow the steps listed below.
Product Service 816-333-8811 or 1-800-522-7658
IF YOUR FREEZE DRYER WAS DAMAGED IN TRANSIT,
YOU MUST FILE A CLAIM DIRECTLY WITH THE FREIGHT
CARRIER. LABCONCO CORPORATION AND ITS DEALERS
ARE NOT RESPONSIBLE FOR SHIPPING DAMAGE.
DO NOT DISCARD THE CARTON OR PACKING MATERIAL
FOR YOUR FREEZE DRYER UNTIL YOU HAVE CHECKED
ALL OF THE COMPONENTS AND INSTALLED AND TESTED
THE FREEZE DRYER.
Acrylic Lid Assembly for -50C models
Stainless Steel Lid Assembly for -84C & -105C models
8L Part #
1 1089005
1
1 7373450
2 1488800
7419300
7208100
Chapter 3: Getting Started
Description
User's Manual
Power Cord See parts list (Appendix A)
Vacuum Hose
Hose Clamp
Baffle
Baffle -84C & -105C Models Only
Comments
USB Flash Drive
-84C Models Only
9
