Technical Specifications

The below table presents the current hardware specification of the FastServe | Live Edit Controller.
CPU
Operating System
Memory
System hard drive
LCD
Controls
Channel configurations
Super slow motion configurations
Data interfaces
Input devices
Dimensions (H x W x D)
Weight
Power consumption
Environmental conditions
Atom N270
Linux
1 GB RAM
8 GB SSD
5.7-inch (144.8 mm) 640x480 TFT color touchscreen
37 illuminated push buttons, 3 million operations minimum; user-
configurable jog wheel; T-bar controller
8-channel server
7 in / 1 out
6 in / 2 out (PVW-PGM / 2PGM / MultiPGM)
4 in / 4 out
(Adding a second controller enables two more outputs to be configured)
Supports 2x, 3x, 4x, and 6x normal speed cameras, combined with
single phase camera recording channels
1 x Serial
2 x USB
2 x 1Gb Ethernet
1 x VGA
Support for external USB keyboard and USB mouse
7.1 x 11 x 11.2 inches (180 x 280 x 285 mm)
10.6 lbs (4.8 kg) approximate
100–240V, 47–63 Hz, 60w (max)
Operating temperature: 41°–104°F (5°–40°C)
Storage temperature: -40°–158°F (-40°–70°C)
Humidity: 90% max
