4. Set the following information:
ONBOOT=yes (not used Ethernet ports should have value "no")
IPADDR=
HWADDR= (use data from the previous step)
NETMASK=
GATEWAY=10.10.0.254
n
The gateway parameter is mandatory for NEXIS. Otherwise, the NEXIS client cannot find the NEXIS
server by name. It needs to be the same gateway as the NEXIS server connected to it.
5. To save the file, type
:wq!
and press Enter.
n
Assign IP addresses for the eth1, eth2, eth3 and eth4 ports in the same way.
• eth0 and eth1 are 1GB ports, while eth2 and eth4 are 10GB ports.
n
When working with Avid PIVOT, it is required that the FastServe servers need to be in the same
subnets, due to UDP communication.
After applying all changes to your network configuration, from a terminal emulator use the following
command to restart the network configuration:
systemctl restart network

Updating the Network Configuration File

The network configuration file is used to specify information about the desired network.
To update the network configuration file:
1. Open the vim editor and type:
vim /etc/sysconfig/network
2. Press Insert to enter the Editing mode.
3. Set the following parameters:
- HOSTNAME="OVS_NAME"
- GATEWAY= (enter the gateway available in your network).
- GATEWAYDEV=eth0 (write a basic network number).
4. Press Esc to exit the Editing mode.
5. To save the file, type
:wq!
and press Enter.
After applying all changes to your network configuration, from a terminal emulator use the
following command to restart the network configuration:
systemctl restart network
If you encounter any problems, see the Troubleshooting 10GB Connection Issues
46
chapter.
