Technical Specifications - Server

Mechanical specifications
• Rack 19" 3U
• Height 130mm
• Width 443mm
• Depth 790mm
• Weight 48kg (approx.)
Power supply
Redundant power supply, 2X 1500W (max) 100-240V 47-63hz
Video CODECs
UHD HQX (1456, 1745 Mbps)
XDCAM HD (50 Mbps)
DNxHD SQ (145, 120, 290 Mbps)
DNxHD HQX (220, 185, 440 Mbps)
Recording capacity - 16x2TB
DNxHR HQX (1456 Mbps) - 25 h (approx.)
XDCAM HD (50 Mbps) - 99 h (approx.)
DNxHD SQ (120 Mbps) – 250h (approx.)
DNxHD HQX (440 Mbps) – 77h (approx.)
Available I/O configurations
4 UHD channels
8 HD channels
Channel configurations
Fully Flexible
4in / 0out
3in / 1out
2in / 2out
1in / 3out
0in / 4out
8in / 0out
The FastServe | Live Edit Server UHDS (UHD Server) |
9
