Video Channel Specifications

This section describes the specifications regarding video channels.
Available I/O Configurations:
• All UHDS model servers support 4xUHD bi-directional channels or 8xHD bi-directional
channels.
The following also applies:
• PAL, NTSC, 1080i 50/59.94, 720p 50/59.94, 1080p 50/59.94

Channel Configuration

The FastServe | Live Edit or FastServe | Ingest server provides Fully Flexible I/O setup.
- 4in / 0out
- 3in / 1out
- 2in / 2out
- 1in / 3out
- 0in / 4out
- 8in / 0out
For cabling information, see
page 23.

Video Codecs

Video Formats and Compression Rates

The video formats and their compression rates are listed in the table below:
Video Format
- UHD HQX
- XDCAM HD
UHD
"UHD Configurations" on page 21
Includes the following compression rates:
• 1456 Mbps
• 1745 Mbps
Includes the following compression rates:
• 50 Mbps
HD
- 7in / 1out
- 6in / 2out
- 5in / 3out
- 4in / 4out
- 3in / 5out
- 2in / 6out
- 1in / 7out
- 0in / 8out
and "HD Configurations" on
Compression Rates
